Ductile Iron AODD Pumps

Get a Price/Quote

Product Details:

Features Heavy Duty
Material Mild Steel
Pressure High
Usage Industrial
Pump Type aodd pumps
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Ductile Iron AODD Pumps Price And Quantity

Ductile Iron AODD Pumps Product Specifications

Features Heavy Duty
Usage Industrial
Pump Type aodd pumps
Pressure High
Material Mild Steel

Product Description

Specification

	SDP 50 CIX with Neoprene / Nitrile / Santoprene / Hytrel / Viton fitments
Maximum Discharge	592 litres/min (156 US gallons/min)
Suction Head Dry	7.3 meters (24 feet)
Suction Head Wet	9.5 meters (31 feet)
Pump Weight	48 kgs (105 lbs)
Max Solid Passage	6.4 mm (1/4”)
Air Distribution System	SDP MaxFlo, MOC aluminium, acetal and CFT seals
Balls / Seals	Santoprene or Hytrel or Nitrile or Neoprene or Viton
Air Inlet	1/2” NPT/BSPT/BSPP
Fluid Inlet, Fluid Outlet	2” NPT/BSPT/BSPP

REPAIR KITS for SDP 50 CIX

Repair KIT Ordering No	Suitable for
203 97 10N	SDP 50 CIN
203 97 10B	SDP 50 CIB
203 97 10S	SDP 50 CIS
203 97 10H	SDP 50 CIH
203 97 10V	SDP 50 CIV
203 97 10T	SDP 50 CIT

AIR VALVE REPLACEMENT KITS for SDP 50 CIX

Replacement KIT Ordering No	Suitable for
203 97 12	NPT Fitted CIX Pumps With Any Diaphragm Variant
203 97 10B	BSPT Fitted CIX Pumps With Any Diaphragm Variant
203 97 10S	BSPP Fitted CIX Pumps With Any Diaphragm Variant
